IntaRNA 4197128

Input and runtime details for job 4197128 (precomputed example)

Sequence Parameters

? Query ncRNA (short) in FASTA[.fa]
? Target RNA (long) in FASTA[.fa]
? Target NCBI RefSeq IDNC_000913
? All repliconsyes
? Extract sequences aroundstart codon
? nt up (1-300)75
? nt down (1-300)75

Output Parameters

? Number of (sub)optimal interactions1
? Suboptimal interaction overlap can overlap in query
? Max. absolute energy of an interaction0
? Max. delta energy above mfe of an interaction100

Seed Parameters

? Min. number of basepairs in seed7
? Max. Number of mismatches in seed0
? Maximal energy0
? Minimal unpaired probability (each)0
? Seed position (query)not provided
? Seed position (target)not provided

Folding Parameters

? Temperature for energy computation37.0
? Access. query: folding window size150
? Access. query: max. basepair distance100
? Access. target: folding window size150
? Access. target: max. basepair distance100
? Energy parameter set (Vienna package) Turner model, 2004

Job ID 4197128 (server version trunk)

?Job Submitted & Queued@ Wed Sep 27 16:47:05 CEST 2017
?Processing Started@ Wed Sep 27 16:47:21 CEST 2017
?IntaRNA Finished & Post-Processing@ Wed Sep 27 17:28:02 CEST 2017
?Post-Processing Finished@ Wed Sep 27 17:28:03 CEST 2017
?Job Completed@ Wed Sep 27 17:28:07 CEST 2017
 DIRECT ACCESS: http://rna.informatik.uni-freiburg.de:80/RetrieveResults.jsp?jobID=4197128&toolName=IntaRNA ( 30 days expiry )

The job description you specified

RyhB - example

? Output download complete results [zip]

Downloadable files

[csv]
[txt]
[png] [pdf] [ps]
[png] [pdf] [ps]
[html] [pdf]


heatmap

? Identified Interactions for NC_000913 Escherichia coli str. K-12 substr. MG1655

Sort by selecting a column name:
p-value fdr value Target Position Query Position Energy Gene Annotation
0.0001433 0.46232 b1683 83 -- 108 RyhB 38 -- 66 -21.43070 sufB component of SufBCD Fe-S cluster assembly scaffold
0.0002853 0.46232 b1181 93 -- 144 RyhB 37 -- 88 -20.31170 ycgN UPF0153 family cysteine cluster protein
0.0003631 0.46232 b0894 38 -- 59 RyhB 42 -- 62 -19.91150 dmsA dimethyl sulfoxide reductase anaerobic subunit A
0.0006013 0.47608 b3743 115 -- 138 RyhB 37 -- 60 -19.05930 asnC transcriptional activator of asnA autorepressor
0.0006231 0.47608 b4255 11 -- 33 RyhB 39 -- 61 -18.99840 rraB protein inhibitor of RNase E
0.0014144 0.70681 b3885 128 -- 150 RyhB 41 -- 66 -17.56810 yihX alpha-D-glucose-1-phosphate phosphatase anomer-specific
0.0017673 0.70681 b2170 43 -- 69 RyhB 2 -- 24 -17.16990 setB lactose/glucose efflux system
0.0019348 0.70681 b0181 2 -- 72 RyhB 5 -- 88 -17.00680 lpxA UDP-N-acetylglucosamine acetyltransferase
0.0021128 0.70681 b2822 109 -- 139 RyhB 37 -- 63 -16.84760 recC exonuclease V (RecBCD complex) gamma chain
0.0021345 0.70681 b4019 66 -- 82 RyhB 43 -- 58 -16.82910 metH homocysteine-N5-methyltetrahydrofolate transmethylase B12-dependent

Details of Selected Interaction Download Interaction Details

Target

Query





Job resubmission

Use the following button if you want to resubmit the job with altered input or parameterization:
Feeds the job parameters to the input page to resubmit the job.

de.NBI usability assessment

Please support us by filling this short quality survey for evaluating this de.NBI service.

When using IntaRNA please cite :

Results are computed with IntaRNA version 2.0.5 (wrapper 1.1.2) linking Vienna RNA package 2.3.1
