IntaRNA 1972078

Input and runtime details for job 1972078 (precomputed example)

Sequence Parameters

? Query ncRNA (short) in FASTA[.fa]
? Index first query position1
? Target RNA (long) in FASTA[.fa]
? Target NCBI RefSeq IDNC_000913
? All repliconsyes
? Extract sequences aroundstart codon
? nt upstream (1-300)75
? nt downstream (1-300)75
? Index first target position-75

Output Parameters

? Number of interactions per RNA pair1
? Suboptimal interaction overlap can overlap in query
? Max. interaction lengthnot provided
? Max. absolute energy of an interaction0
? Max. delta energy above mfe of an interaction100
? No lonely base pairsyes
? No GU at helix endsyes

Seed Parameters

? Min. number of basepairs in seed7
? Max. Number of mismatches in seed0
? Maximal energy0
? Minimal unpaired probability (per RNA)0
? Seed position (query)not provided
? Seed position (target)not provided
? Ignore seeds with GU base pairsno
? Ignore seeds with GU endsyes

Folding Parameters

? Temperature for energy computation37.0
? Access. query: folding window size150
? Access. query: max. basepair distance100
? Access. target: folding window size150
? Access. target: max. basepair distance100
? Energy parameter set (Vienna package) Turner model, 2004

Job ID 1972078 (server version trunk)

?Job Submitted & Queued@ Mon Jan 27 14:13:56 CET 2020
?Processing Started@ Mon Jan 27 14:16:07 CET 2020
?IntaRNA Finished & Post-Processing@ Mon Jan 27 14:17:05 CET 2020
?Post-Processing Finished@ Mon Jan 27 14:18:21 CET 2020
?Job Completed@ Mon Jan 27 14:18:31 CET 2020
 DIRECT ACCESS: http://rna.informatik.uni-freiburg.de:80/RetrieveResults.jsp?jobID=1972078&toolName=IntaRNA ( 30 days expiry )

The job description you specified

MicC - E. coli


? Output download complete results [zip]

Downloadable files

[csv]
[png] [pdf]
[png] [pdf]
[txt]
[html] [pdf] [png]


heatmap

? Identified Interactions for NC_000913 Escherichia coli str. K-12 substr. MG1655

Sort by selecting a column name
Target Start(T) End(T) Query Start(Q) End(Q) Energy p-value fdr gene annotation
b2215 -67 -15 MicC 1 70 -21.53 5.2e-06 0.0190476 ompC outer membrane porin protein C
b0393 -71 -57 MicC 40 55 -16.11 0.0004508 0.7974595 rdgC nucleoid-associated ssDNA and dsDNA binding protein competitive inhibitor of RecA function
b1835 -15 11 MicC 35 58 -15.19 0.0008759 0.7974595 rsmF 16S rRNA m(5)C1407 methyltransferase SAM-dependent
b2239 56 74 MicC 41 66 -14.71 0.0012277 0.7974595 glpQ periplasmic glycerophosphodiester phosphodiesterase
b1346 -13 5 MicC 41 58 -14.56 0.0013626 0.7974595 ydaQ Rac prophage conserved protein
b4032 -14 21 MicC 31 65 -14.02 0.0019743 0.7974595 malG maltose transporter subunit
b4403 -8 11 MicC 1 21 -13.87 0.0021857 0.7974595 yjtD putative methyltransferase
b2314 -9 11 MicC 45 65 -13.85 0.0022155 0.7974595 dedD membrane-anchored periplasmic protein involved in septation
b3751 56 74 MicC 41 59 -13.8 0.0022915 0.7974595 rbsB D-ribose ABC transporter periplasmic binding protein ribose chemotaxis receptor
b2920 2 18 MicC 51 66 -13.62 0.0025864 0.7974595 scpC propionyl-CoA:succinate CoA transferase
Rows: 1-10 11-20 21-30 31-40 41-50 51-60 61-70 71-80 81-90 91-100 all

Details of Selected Interaction Download Interaction Details

Target

Query





Job resubmission

Use the following button if you want to resubmit the job with altered input or parameterization:
Feeds the job parameters to the input page to resubmit the job.

de.NBI usability assessment

Please support us by filling this short quality survey for evaluating this de.NBI service.

When using IntaRNA please cite :

Results are computed with IntaRNA version 3.1.3 linking Vienna RNA package 2.4.14
