Input and runtime details for job 7814698 (precomputed example)

Sequence Parameters

	Query ncRNA (short) in FASTA		[.fa]
	Index first query position		1
	Target RNA (long) in FASTA		[.fa]
	Target NCBI RefSeq ID		NC_002516
	All replicons		yes
	Extract sequences around		start codon
	nt upstream (1-300)		75
	nt downstream (1-300)		75
	Index first target position		-75

Output Parameters

	Number of interactions per RNA pair		1
	Suboptimal interaction overlap		can overlap in query
	Max. interaction length		not provided
	Max. absolute energy of an interaction		0
	Max. delta energy above mfe of an interaction		100
	No lonely base pairs		yes
	No GU at helix ends		yes

Seed Parameters

	Min. number of basepairs in seed		7
	Max. Number of mismatches in seed		0
	Maximal energy		0
	Minimal unpaired probability (per RNA)		0
	Seed position (query)		not provided
	Seed position (target)		not provided
	Ignore seeds with GU base pairs		no
	Ignore seeds with GU ends		yes

Folding Parameters

	Temperature for energy computation		37.0
	Access. query: folding window size		150
	Access. query: max. basepair distance		100
	Access. target: folding window size		150
	Access. target: max. basepair distance		100
	Energy parameter set (Vienna package)		Turner model, 2004

Job ID 7814698 (server version trunk)

	Job Submitted & Queued		@ Fri Jan 07 21:23:03 CET 2022
	Pre-Processing Started		@ Fri Jan 07 21:23:24 CET 2022
	IntaRNA Started		@ Fri Jan 07 21:25:48 CET 2022
	IntaRNA Finished & Post-Processing		@ Fri Jan 07 21:26:49 CET 2022
	Post-Processing Finished		@ Fri Jan 07 21:27:12 CET 2022
	Job Completed		@ Fri Jan 07 21:27:13 CET 2022

DIRECT ACCESS: http://rna.informatik.uni-freiburg.de/RetrieveResults.jsp?jobID=7814698&toolName=IntaRNA ( 30 days expiry )

Description of the job

PrrF1 - Pseudomonas aeruginosa

Output [zip]

Downloadable files

	IntaRNA result table:		[csv]
	Target region plot		[png] [pdf]
	Query region plot		[png] [pdf]
	Functional enrichment file		[txt]
	Functional annotation chart		[html] [pdf] [png]

Target region plot

Query region plot

Function

Identified Interactions for NC_002516 Pseudomonas aeruginosa PAO1

Show rows: 1-10 11-20 21-30 31-40 41-50 51-60 61-70 71-80 81-90 91-100 all

Sort by selecting a column name.

Target	Start(T)	End(T)	Start(seed-T)	End(seed-T)	ED(T)	Query	Start(Q)	End(Q)	Start(seed-Q)	End(seed-Q)	ED(Q)	Energy	E(hybrid)	E_norm	RRI subseqs	RRI details	Seq(T)	Seq(Q)	p-value	fdr	gene	geneID	annotation
PA3621	44	55	46	52	2.52	PrrF1	71	82	74	80	4.1	-19.78	-26.4	-1.97249	CCGACUGCGUGG&CCACGCAGUCGG	((((((((((((&))))))))))))	CGGGUCUGACGGACUACCGCACAAGCUGCUAGAAUCGCGCGCGCUUAGCCGCCCGCCUGAGGAGAGAACUAGAAAAUGACCUUCGUCGUCACCGACAACUGCAUCAAGUGCAAAUACACCGACUGCGUGGAAGUCUGCCCGGUAGACUGC	UUGACAUGGAAAUGAGAAUCAUUAUUAUGUCACUCAACUGGUCGCGAGAUCAGCCGGUAAGCUGAGAGACCCACGCAGUCGGACUCUUCAGAUUAUCUCCUCAUCAGGCUAAUCACGGUUUUUGACCCGGCACUUUGCCGGGUCUUUUUUU	5.15e-05	0.1650844	fdxA	880230	ferredoxin I
PA0119	53	73	67	73	8.72	PrrF1	101	121	101	107	2.24	-19.45	-30.41	-1.93959	AAGUCGUGAUUGGCCUGGUGA&UCAUCAGGCUAAUCACGGUUU	(((((((((((((((((((((&)))))))))))))))))))))	AACUGGUCAGACCGGUAAUACCACAAUAAAAAUGCGUUCAUCGCCCGCCUCCGCGAGGCCCGAUGGAAGCGCCGAAUGGAGACUCCUGCGAUGUUCAUCAAGCGCUGUUCCCGCUCGAUAUUCCUGCAAGUCGUGAUUGGCCUGGUGAUA	UUGACAUGGAAAUGAGAAUCAUUAUUAUGUCACUCAACUGGUCGCGAGAUCAGCCGGUAAGCUGAGAGACCCACGCAGUCGGACUCUUCAGAUUAUCUCCUCAUCAGGCUAAUCACGGUUUUUGACCCGGCACUUUGCCGGGUCUUUUUUU	6.97e-05	0.1650844		877578	C4-dicarboxylate transporter DctA
PA2831	-26	-6	-26	-20	8.23	PrrF1	99	118	112	118	2.24	-18.5	-28.97	-1.84485	CCGUGAUUUCGCCCGAUGAGG&CCUCAUCAGGCUAAUCACGG	((((((((..(((.(((((((&))))))).))).))))))))	UAUCCAUGGUCGCUUUGACAGCCGCGAGCCAGCCCCGGAACAUGCGGGUCCGUGAUUUCGCCCGAUGAGGUUCCCAUGCAGAUCCGCGCCGAUUUCGACAGCGGCAACAUCCAGGUCAUCGAUGCCAGCGAUCCCCGCCGGAUCCGCCUG	UUGACAUGGAAAUGAGAAUCAUUAUUAUGUCACUCAACUGGUCGCGAGAUCAGCCGGUAAGCUGAGAGACCCACGCAGUCGGACUCUUCAGAUUAUCUCCUCAUCAGGCUAAUCACGGUUUUUGACCCGGCACUUUGCCGGGUCUUUUUUU	0.0001603	0.246324		882811	'Product name confidence: class 4 (Homologs of previously reported genes of unknown function or no similarity to any previously reported sequences)'
PA1103	-16	54	-16	-10	20	PrrF1	38	102	96	102	22.18	-17.95	-60.13	-1.79	GAGGAGAUGAUCUGAGGUGGUCCCCCACGACAAGGACAAAGACAAUCCCAGCGAACUGAUCCGCGGCAAG&CUGGUCGCGAGAUCAGCCGGUAAGCUGAGAGACCCACGCAGUCGGACUCUUCAGAUUAUCUCCUC	(((((((((((((((((..((((...((.....((..........((.((((...((((((((((((.((&)).)))))).)))))).......)))).))...)).....)).)))).)))))))))))))))))	UCACCAUUGCCCGGCGCAUGGCCGAGUCCGGCGAUAUCGUGCUGGGCGGCAAGGGUGGCGAGGAGAUGAUCUGAGGUGGUCCCCCACGACAAGGACAAAGACAAUCCCAGCGAACUGAUCCGCGGCAAGGACGUGGCGGCCUUCGGCCUC	UUGACAUGGAAAUGAGAAUCAUUAUUAUGUCACUCAACUGGUCGCGAGAUCAGCCGGUAAGCUGAGAGACCCACGCAGUCGGACUCUUCAGAUUAUCUCCUCAUCAGGCUAAUCACGGUUUUUGACCCGGCACUUUGCCGGGUCUUUUUUU	0.0002537	0.246324		880874	flagellar assembly protein FliH
PA1571	-33	-7	-16	-10	6.81	PrrF1	96	121	99	105	5.54	-17.92	-30.27	-1.78701	AGACUGCCGAUAAACCUGAUGAGGAGA&UCUCCUCAUCAGGCUAAUCACGGUUU	((((((..(((...(((((((((((((&)))))))))))))...))).))))))	CGACAUCCGCCGUUUGUCACGGCGGUUUCAUCUGCGCUCCCUAGACUGCCGAUAAACCUGAUGAGGAGACGGGCAAUGAAUUCGCAACACACCGAUACCGCCAAGCGCCGCGUGAUCCCCUUCAAUACGCAGCAGCACACCGGUGGCGCC	UUGACAUGGAAAUGAGAAUCAUUAUUAUGUCACUCAACUGGUCGCGAGAUCAGCCGGUAAGCUGAGAGACCCACGCAGUCGGACUCUUCAGAUUAUCUCCUCAUCAGGCUAAUCACGGUUUUUGACCCGGCACUUUGCCGGGUCUUUUUUU	0.00026	0.246324		877740	'Product name confidence: class 4 (Homologs of previously reported genes of unknown function or no similarity to any previously reported sequences)'
PA5300	-45	-27	-33	-27	4.09	PrrF1	99	116	99	105	2.19	-16.71	-22.99	-1.66635	GUGAUAAGCCACGAUGAGG&CCUCAUCAGGCUAAUCAC	(((((.((((..(((((((&))))))).)))).)))))	GGCCCGCAGUGAUCGGUAUCGUGCCCGGGUGUGAUAAGCCACGAUGAGGGUGUAAGGGUGAACCUGAUUAAAAAAAUGCUGGCGGCCCAAGCUGCCGUGUUGGCCCUGUGGGCUGUAAGCGCUCAGGCUACGACCACUGACGAUGCGAUC	UUGACAUGGAAAUGAGAAUCAUUAUUAUGUCACUCAACUGGUCGCGAGAUCAGCCGGUAAGCUGAGAGACCCACGCAGUCGGACUCUUCAGAUUAUCUCCUCAUCAGGCUAAUCACGGUUUUUGACCCGGCACUUUGCCGGGUCUUUUUUU	0.0006743	0.5323598	cycB	878483	cytochrome C5
PA2715	44	55	46	52	5.75	PrrF1	71	82	74	80	4.1	-16.49	-26.34	-1.64441	CCGACUGCGUGG&CCACGCAGUCGG	((((((((((((&))))))))))))	ACAAGUACGUGCCGGCGCGCCUGGAACGGCUGGCGACGCCCGCCGCUACGAACGCCUGAGCCAGGGAGGACGAUCAUGACCUUCGUCGUGCUGGAAGAAUGCAUCCGCUGCAAACACACCGACUGCGUGGAAGUCUGUCCCGUGGACUGC	UUGACAUGGAAAUGAGAAUCAUUAUUAUGUCACUCAACUGGUCGCGAGAUCAGCCGGUAAGCUGAGAGACCCACGCAGUCGGACUCUUCAGAUUAUCUCCUCAUCAGGCUAAUCACGGUUUUUGACCCGGCACUUUGCCGGGUCUUUUUUU	0.000796	0.5386646		882611	ferredoxin
PA5490	-20	41	35	41	15.31	PrrF1	67	120	67	73	14.03	-16.18	-45.52	-1.6135	AGCCGUAAUUGGAUUAGCUGAUGAACAAACUUCUCGUGAGUCUGCUGUUGACCCUGGGUCU&AGACCCACGCAGUCGGACUCUUCAGAUUAUCUCCUCAUCAGGCUAAUCACGGUU	((((((.....(((((((((((((.......(((...((((((((((.......(((((((&)))))))..))).)))))))...)))........)))))).)))))))))))))	GCAACCAUCCAGUGGAUGGUGAAGAAGUAGCCGAAGCCCACUAUCUUUCACCCUUAGCCGUAAUUGGAUUAGCUGAUGAACAAACUUCUCGUGAGUCUGCUGUUGACCCUGGGUCUGACCGGCCUUGCCCAUGCCGCUGGCGAUGCCGCC	UUGACAUGGAAAUGAGAAUCAUUAUUAUGUCACUCAACUGGUCGCGAGAUCAGCCGGUAAGCUGAGAGACCCACGCAGUCGGACUCUUCAGAUUAUCUCCUCAUCAGGCUAAUCACGGUUUUUGACCCGGCACUUUGCCGGGUCUUUUUUU	0.0010019	0.5771389	cc4	877732	cytochrome C4
PA5351	-10	22	16	22	4.66	PrrF1	71	99	71	77	6.14	-15.79	-26.59	-1.5746	GAGGUAAACAAUGAAGAAGUGGCAAUGCGUGG&CCACGCAGUCGGACUCUUCAGAUUAUCUC	(((((((....((((((.((.....(((((((&))))))).....))))))))..)))))))	GGGCAGGUUGGCGGACAGGGUGGAUUUGUUAUAGGUUGCCGGCGCUGAACCGUGGUAACCCGCCCGAGGUAAACAAUGAAGAAGUGGCAAUGCGUGGUGUGUGGACUGAUCUAUGACGAGGCCAAAGGCUGGCCGGAAGAAGGCAUCGAG	UUGACAUGGAAAUGAGAAUCAUUAUUAUGUCACUCAACUGGUCGCGAGAUCAGCCGGUAAGCUGAGAGACCCACGCAGUCGGACUCUUCAGAUUAUCUCCUCAUCAGGCUAAUCACGGUUUUUGACCCGGCACUUUGCCGGGUCUUUUUUU	0.0013306	0.5771389	rubA1	879562	rubredoxin
PA3291	11	32	24	30	8.2	PrrF1	70	90	72	78	5.87	-15.78	-29.85	-1.57361	UGAUGAGUUUGAUCUGUGUGGG&CCCACGCAGUCGGACUCUUCA	(((.((((((((.(((((((((&))))))))))))))))).)))	UACUUCAGCUGCCUGUUAUGCGCCGUUUCAUCCUGAAUAUCCGAAUAAAGGUUACUUUGAUAUGAGGGGUAUGUCAUGCAGAAGUUGAUGAGUUUGAUCUGUGUGGGAACUAAAAAGUCCAUUGGGUUGGUGGUUUUUCUCAGCACCUUC	UUGACAUGGAAAUGAGAAUCAUUAUUAUGUCACUCAACUGGUCGCGAGAUCAGCCGGUAAGCUGAGAGACCCACGCAGUCGGACUCUUCAGAUUAUCUCCUCAUCAGGCUAAUCACGGUUUUUGACCCGGCACUUUGCCGGGUCUUUUUUU	0.0013402	0.5771389		882454	'Product name confidence: class 4 (Homologs of previously reported genes of unknown function or no similarity to any previously reported sequences)'

Rows: 1-10 11-20 21-30 31-40 41-50 51-60 61-70 71-80 81-90 91-100 all

Details of Selected Interaction Download Interaction Details

Target

Query

Energy

Hybridization Energy

Unfolding Energy - Target

Unfolding Energy - Query

Position - Target

Position - Query

Position Seed - Target

Position Seed - Query

Job resubmission

Use the following button if you want to resubmit the job with altered input or parameterization:

usability assessment

Please support us by filling this short quality survey for evaluating this

service.

When using IntaRNA please cite :

Martin Mann, Patrick R. Wright, and Rolf Backofen
IntaRNA 2.0: enhanced and customizable prediction of RNA–RNA interactions
Nucleic Acids Research, 2017, 45 (W1), W435–W439.
Patrick R. Wright, Jens Georg, Martin Mann, Dragos A. Sorescu, Andreas S. Richter, Steffen Lott, Robert Kleinkauf, Wolfgang R. Hess, and Rolf Backofen
CopraRNA and IntaRNA: predicting small RNA targets, networks and interaction domains
Nucleic Acids Research, 2014, 42 (W1), W119-W123.
Anke Busch, Andreas S. Richter, and Rolf Backofen
IntaRNA: efficient prediction of bacterial sRNA targets incorporating target site accessibility and seed regions
Bioinformatics, 2008, 24 (24), 2849-56.
Martin Raden, Syed M Ali, Omer S Alkhnbashi, Anke Busch, Fabrizio Costa, Jason A Davis, Florian Eggenhofer, Rick Gelhausen, Jens Georg, Steffen Heyne, Michael Hiller, Kousik Kundu, Robert Kleinkauf, Steffen C Lott, Mostafa M Mohamed, Alexander Mattheis, Milad Miladi, Andreas S Richter, Sebastian Will, Joachim Wolff, Patrick R Wright, and Rolf Backofen
Freiburg RNA tools: a central online resource for RNA-focused research and teaching
Nucleic Acids Research, 46(W1), W25-W29, 2018.

Results are computed with IntaRNA version 3.2.0 linking Vienna RNA package 2.4.14
